X-ray Diffraction Imaging
Bio/medical Systems

Ever since their discovery in 1895, X-rays have been used to provide patients with improved medical care and have given doctors tools for better understanding disease

X-Ray

While traditional, transmission X-ray images do a wonderful job at some tasks (like diagnosing broken bones)...

...these transmission X-ray images can be misleading or incapable of delivering the information needed for an accurate diagnosis (like in evaluating cancer)

Quadridox's X-ray Diffraction Imaging systems go beyond traditional X-ray imagery to provide the information needed to make accurate and timely diagnoses

Photo of breast tissue
Traditional X-ray image
XRDI image
XRD tissue 'fingerprints'
Healthy tissue
Cancerous tissue
Healthy tissue

Cancer tissue imaging

BioSpecx XRDI system

Quadridox's BioSpecx system is the first specimen radiography system to employ XRD technology to directly identify cancer ​

breast_photo.tiff
breast.tif

Other bio/medical/agricultural applications

Screenshot 2024-04-29 at 10.43.32 AM.png
  • Tissue biobanking​

  • Forensics

  • Basic research

  • Biospecimen analysis

  • Pathology workflow

  • Pharmaceutical inspection

  • Food inspection

  • Anthropology

Screenshot 2024-04-29 at 2.09.25 PM.png
Screenshot 2024-04-29 at 10.36.27 AM.png

1. Stryker, S., Greenberg, J.A., McCall, S.J. et al. Scii Rep 11, 10585 (2021).
